Canon EOS C80 6K Full-Frame Cinema Camera (Canon RF)

6K Full-Frame Cinema Capture in a Mirrorless Form

Offering exceptional 6K30 full-frame capture in a compact form, the Canon EOS C80 6K Full-Frame Cinema Camera melds the EOS C400's CMOS sensor with a lightweight design similar to the EOS C70. Ideal for fast-paced capture and solo operators, this digital camera features triple ISO bases of 800, 3200, and 12,800 in log/raw, upgraded Dual Pixel CMOS AF II autofocus, and simultaneous 12G-SDI and HDMI video output. The EOS C80's RF mount provides compatibility with fast, reliable Canon RF lenses, and a motorized ND filter wheel enables on-the-fly exposure tweaking.

Introducing the Canon EOS C80 Cinema Camera: Redefining Flexibility

The 6K full-frame CMOS sensor at the heart of the C80 camera enables it to offer exceptionally low noise, increased sensitivity efficiency, and better 4K imagery via 6K oversampling. All this is possible thanks to the improved light capture technology of the back-illuminated, stacked CMOS sensor.

Multiple Recording Formats

The C80's multiple recording formats include up to full-frame 6K30 Canon Cinema RAW Light LT and cropped S35 up to 4K30 in RAW ST and 4K60 in RAW LT.

Oversampled 4K 120p or 2K 180p with maximized detail is available, all with 4:2:2 10-bit color.

Slow and fast motion can be captured at rates up to UHD 4K120 in HEVC and AVC codecs.

Make your editing process easier using XF-AVC S and XF-HEVC S codecs, featuring an easier naming system and folder structure, as well as metadata preservation, all within the established MP4 format.

RF Lens Mount

A built-in RF lens mount lends the EOS C80 compatibility with Canon's line of fast, reliable RF-mount lenses with advanced coatings and image stabilization.

With a short flange distance, the RF mount helps to noticeably reduce the camera body's depth, resulting in a more compact design.

Multiple Interfaces Including 12G-SDI

Video outputs include full-size HDMI and 12G-SDI BNC outputs that can be used simultaneously for feeding an onboard monitor, video transmitter, or EVF.

Use the USB-C port for UVC video output or to connect to a smartphone or the Canon GP-E2 GPS receiver.

A BNC connector enables users to input and output timecode, making syncing on multicamera shoots easier.

Note that the BNC port can output either SDI video or timecode but not both simultaneously.

Lens Mount	Canon RF
Sensor Resolution	Actual: 26.67 Megapixel (6202 x 4300) Effective: 19.05 Megapixel (6008 x 3170)
Image Sensor	Full-Frame BSI Stacked CMOS
Image Stabilization	Digital, 5-Axis
ISO/Gain Sensitivity	Native: 100 to 102,400
Internal Recording Modes	Cinema RAW Light 12-Bit UHD 6K (6000 x 3164) at 23.98/24.00/25/29.97 fps [553 to 639 Mb/s] 4368 x 2304 at 23.98/24.00/25/29.97/50/59.94 fps [293 to 678 Mb/s] XF-AVC S Intra 4:2:2 10-Bit 4096 x 2160 at 59.94/60.00 fps [600 Mb/s] 3840 x 2160 at 50/60.00 fps [500 Mb/s] 2048 x 2160 at 59.94/120 fps [300 Mb/s] 1920 x 1080 at 50/120 fps [250 Mb/s] XF-AVC S Intra 4:2:2 10-Bit 4096 x 2160 at 50/59.94/120 fps [250 Mb/s] 3840 x 2160 at 23.98/24.00/25/29.97/120 fps [150 Mb/s] 2048 x 1080 at 23.98/24.00/25/29.97/50/59.94/180 fps [50 Mb/s] 1920 x 1080 at 23.98/24.00/25/29.97/50/59.94/180 fps [120 to 300 Mb/s] XF-AVC S Long GOP 4:2:0 8-Bit 4096 x 2160 at 50/59.94/120 fps [150 Mb/s] 3840 x 2160 at 23.98/24.00/25/29.97/120 fps [100 Mb/s] 2048 x 1080 at 23.98/24.00/25/29.97/50/59.94/180 fps [35 Mb/s] 1920 x 1080 at 23.98/24.00/25/29.97/50/59.94/180 fps [35 Mb/s] XF-HEVC S Intra 4:2:0 8-Bit 2048 x 1080 at 23.98/24.00/25/29.97/50/59.94 fps [9 to 16 Mb/s] 1920 x 1080 at 23.98/24.00/25/29.97/50/59.94/60.00 fps [9 to 16 Mb/s] 1280 x 720 at 23.98/24.00/25/29.97/50/59.94 fps [6 Mb/s] XF-HEVC S Long GOP 4:2:2 10-Bit 4096 x 2160 at 50/59.94/120 fps [225 Mb/s] 3840 x 2160 at 23.98/24.00/25/29.97/120 fps [135 Mb/s] 2048 x 1080 at 23.98/24.00/25/29.97/30.00/50/59.94/180 fps [50 Mb/s] 1920 x 1080 at 23.98/24.00/25/29.97/30.00/50/59.94/180 fps [50 Mb/s] XF-HEVC S Long GOP 4:2:0 10-Bit 4096 x 2160 at 50/59.94/120 fps [150 Mb/s] 3840 x 2160 at 23.98/24.00/25/29.97/120 fps [100 Mb/s] 2048 x 1080 at 23.98/24.00/25/29.97/50/59.94/180 fps [35 Mb/s] 1920 x 1080 at 23.98/24.00/25/29.97/59.94/180 fps [35 Mb/s] XF-HEVC S Long GOP 4:2:0 10-Bit 2048 x 1080 at 23.98/24.00/25/29.97/50/59.94/60.00 fps [9 to 16 Mb/s] 1920 x 1080 at 23.98/24.00/25/29.97/50/59.94 fps [9 to 16 Mb/s] XF-HEVC S Long GOP 4:2:0 8-Bit 1280 x 720 at 23.98/24.00/25/50/59.94 fps [6 Mb/s]
External Recording Modes	SDI/BNC / HDMI / USB 4096 x 2160
Media/Memory Card Slot	Slot 1: SD/SDHC/SDXC Slot 2: SD/SDHC/SDXC
Video I/O	1x BNC (12G-SDI) Output 1x HDMI (Unspecified Signal) Output
Mobile App Compatible	Yes: iOS Only App Name: Remote Camera Control App Functionality: Adjust Settings, Remote Control, View Live Feed
Battery Type	Canon BP-AN Series

Imaging

Lens Mount	Canon RF
Lens Communication	Yes, Cooke /i
Sensor Resolution	Actual: 26.67 Megapixel (6202 x 4300) Effective: 19.05 Megapixel (6008 x 3170)
Image Sensor	Full-Frame BSI Stacked CMOS
Image Stabilization	Digital, 5-Axis
Built-In ND Filter	Mechanical Filter Wheel with 2-Stop (1/4), 4-Stop (1/16), 6-Stop (1/64), 8-Stop (1/256), 10-Stop (1/1024) ND Filters
Internal Filter Holder	No
Capture Type	Stills & Video

Exposure Control

Shutter Type	Electronic Rolling Shutter
Shutter Speed	1/2000 to 1 Second
ISO/Gain Sensitivity	Native: 100 to 102,400
Shutter Angle	11.25 to 360°
Advertised Dynamic Range	16 Stops
White Balance	Range: 2000 to 15,000K Presets: AWB, Daylight, Set A, Set B, Tungsten

Video Capture

Internal Recording Modes	Cinema RAW Light 12-Bit UHD 6K (6000 x 3164) at 23.98/24.00/25/29.97 fps [553 to 639 Mb/s] 4368 x 2304 at 23.98/24.00/25/29.97/50/59.94 fps [293 to 678 Mb/s] XF-AVC S Intra 4:2:2 10-Bit 4096 x 2160 at 59.94/60.00 fps [600 Mb/s] 3840 x 2160 at 50/60.00 fps [500 Mb/s] 2048 x 2160 at 59.94/120 fps [300 Mb/s] 1920 x 1080 at 50/120 fps [250 Mb/s] XF-AVC S Intra 4:2:2 10-Bit 4096 x 2160 at 50/59.94/120 fps [250 Mb/s] 3840 x 2160 at 23.98/24.00/25/29.97/120 fps [150 Mb/s] 2048 x 1080 at 23.98/24.00/25/29.97/50/59.94/180 fps [50 Mb/s] 1920 x 1080 at 23.98/24.00/25/29.97/50/59.94/180 fps [120 to 300 Mb/s] XF-AVC S Long GOP 4:2:0 8-Bit 4096 x 2160 at 50/59.94/120 fps [150 Mb/s] 3840 x 2160 at 23.98/24.00/25/29.97/120 fps [100 Mb/s] 2048 x 1080 at 23.98/24.00/25/29.97/50/59.94/180 fps [35 Mb/s] 1920 x 1080 at 23.98/24.00/25/29.97/50/59.94/180 fps [35 Mb/s] XF-HEVC S Intra 4:2:0 8-Bit 2048 x 1080 at 23.98/24.00/25/29.97/50/59.94 fps [9 to 16 Mb/s] 1920 x 1080 at 23.98/24.00/25/29.97/50/59.94/60.00 fps [9 to 16 Mb/s] 1280 x 720 at 23.98/24.00/25/29.97/50/59.94 fps [6 Mb/s] XF-HEVC S Long GOP 4:2:2 10-Bit 4096 x 2160 at 50/59.94/120 fps [225 Mb/s] 3840 x 2160 at 23.98/24.00/25/29.97/120 fps [135 Mb/s] 2048 x 1080 at 23.98/24.00/25/29.97/30.00/50/59.94/180 fps [50 Mb/s] 1920 x 1080 at 23.98/24.00/25/29.97/30.00/50/59.94/180 fps [50 Mb/s] XF-HEVC S Long GOP 4:2:0 10-Bit 4096 x 2160 at 50/59.94/120 fps [150 Mb/s] 3840 x 2160 at 23.98/24.00/25/29.97/120 fps [100 Mb/s] 2048 x 1080 at 23.98/24.00/25/29.97/50/59.94/180 fps [35 Mb/s] 1920 x 1080 at 23.98/24.00/25/29.97/59.94/180 fps [35 Mb/s] XF-HEVC S Long GOP 4:2:0 10-Bit 2048 x 1080 at 23.98/24.00/25/29.97/50/59.94/60.00 fps [9 to 16 Mb/s] 1920 x 1080 at 23.98/24.00/25/29.97/50/59.94 fps [9 to 16 Mb/s] XF-HEVC S Long GOP 4:2:0 8-Bit 1280 x 720 at 23.98/24.00/25/50/59.94 fps [6 Mb/s]
External Recording Modes	SDI/BNC / HDMI / USB 4096 x 2160
Recording Sensor Crop	Crops to Output Resolution When Using Super35 Mode
Fast-/Slow-Motion Support	Yes
Gamma Curve	Canon Log 2, Canon Log 3, HDR-HLG, Rec709, Rec2020
Built-In Microphone	Stereo
Audio Recording	Cinema RAW Light: 4-Channel 24-Bit 48 kHz LPCM Audio XF-AVC: 4-Channel 24-Bit 48 kHz LPCM Audio XF-AVC S, XF-HEVC S: 4-Channel 24-Bit 48 kHz LPCM Audio XF-AVC S, XF-HEVC S: 2-Channel 16-Bit 48 kHz AAC Audio
IP Streaming	H.264, MPEG2, RTP, RTSP, SRT, UDP 1920 x 1080 at 50i, 50p, 59.94i, 59.94p (4.0 to 9.0 Mb/s)

Interface

Media/Memory Card Slot	Slot 1: SD/SDHC/SDXC Slot 2: SD/SDHC/SDXC
Video I/O	1x BNC (12G-SDI) Output 1x HDMI (Unspecified Signal) Output
Audio I/O	2x Mini XLR Input 1x 1/8" / 3.5 mm TRS Stereo Microphone Input on Camera Body 1x 1/8" / 3.5 mm TRS Stereo Headphone Output
Power I/O	1x Barrel (23.7 to 25VDC) Input
Other I/O	1x RJ45 (XC) Control 1x USB-C Monitor 1x BNC (Timecode) (Shared with Video Output) 1x 2.5 mm Sub-Mini (LANC) Control
Wireless	2.4 / 5 GHz Wi-Fi 5 (802.11ac)
Mobile App Compatible	Yes: iOS Only App Name: Remote Camera Control App Functionality: Adjust Settings, Remote Control, View Live Feed
Global Positioning (GPS, GLONASS, etc.)	No

Monitor

Display Type	Primary Monitor: Included External 3.5" Touchscreen LCD
Resolution	Primary Monitor: 1280 x 720

Focus

Focus Mode

Continuous-Servo AF, Focus Lock AF Area Mode, Manual Focus, One-Shot AF

Power

Battery Type	Canon BP-AN Series
Power Consumption	≤19.6 W

Environmental

Operating Conditions	32 to 104°F / 0 to 40°C up to 85% Humidity
Storage Conditions	23 to 113°F / -5 to 45°C up to 60% Humidity

General

Shoe Mount	1x Intelligent Hot Shoe
Tripod Mounting Thread	1x 3/8"-16 Female 2x 1/4"-20 Female
Accessory Mounting Thread	No
Dimensions (W x H x D)	6.3 x 5.4 x 4.6" / 160 x 138 x 116 mm 10.9 x 6.8 x 6.3" / 276 x 173 x 160 mm (With Handle, Included Battery, Mic Holder)
Weight	2.87 lb / 1.30 kg (Body Only) 3.406 lb / 1.545 kg (With Battery, Handle)

Packaging Info

Package Weight	6.385 lb
Box Dimensions (LxWxH)	11 x 8.9 x 7.4"
